The Main Technical Parameters of the Mechanical Part:
●Accuracy class:1.0 (at 20℃); 2.0 (at -40℃～＋65℃）；
●Contact capacity: AC/DC 250V, 1000 VA / 500 W.
● Contact resistance: ≤0.5 Ohms.
● Pressure display range: -0.1 ~ 0.9MPa ;
●Sealing performance: ≤1× 10-8mbar.l/s (helium test);
●Ant-vibration performance: 20m/s2;
●Shock resistance: 50 g;
●Contacts: up to 4 pairs, change-over;
●Housing protection class: IP65;
The Main Technical Parameters of the Remote (Electrical) Part:
● Accuracy class:1.5 (at full temperature）；
● Work Power: DC 10~30V / (DC24V, 2mA)
● Work Pressure:-0.1MPa~0.9MPa ( gauge pressure), or 0MPa~1.0MPa
(Absolute pressure);
● Temperature compensation range: -40 ~80℃ (Gaseous state)
● Communicate mode: RS485 (ModBus communicate protocol),
4-20mA(two-wire system), CAN, HART Protocol, fiber-optic
communication, wireless communication, and so on. It fits our hub
and meet the communication requirement of IEC61850.
● According to the client’s need, it can display the data conveniently
(output LED).
